ETRM-Interface Impementation Guide

This guide aims to help with the implementation of an automatic interface between dispoGas and your ETRM (or via a Middleware Solution). It describes the business cases involved, the dispoGas API endpoints and describes the expected dataflows in detail.

Business Processes​

dispoGas can be used for the following business processes (roughly following the EASEE Gas CBP 2018-001-02 Harmonised Gas Role Model - Business Process perspective.

Send VTP Nominations​

A nomination at a virtual trading point to the responsible Area Coordinator indicate the traded quantities with other counterparties.

Send Gas Flow Nominations​

A nomination to a Transport, Storage or LNG System Operator of the flow that should inject into or withdraw from the system.

Send (or receive) B2B nominations​

A nomination to a counterparty, indicating the requested utilization of a flexible (swing) contract.

Data Transfer to dispoGas​

Typically, the sequence of any of these processes is as following (Middleware is optional and could also be solved in the ETRM itself):

Data Transfer from dispoGas​

The transfer from dispoGas to the ETRM system is only required for the processes

  • Send Gas Flow Nominations
  • Send (or receive) B2B nominations

and should follow the following sequence diagram.

info

It is important, that there is an 1:1 relationship between the dispoGas Nomination Track and the ETRM trade or timeseries.

API Implementation​

See Detailed description
